1″ Jetting Nozzles
1″ jetting nozzles handle heavy-duty high-pressure sewer cleaning in large-diameter pipes and demanding industrial environments. Professionals use these nozzles on hydro jetting trucks to generate strong rear thrust and remove grease, roots, sediment, and hardened blockages. We machine each nozzle from stainless steel to ensure durability, corrosion resistance, and stable hydraulic performance at high pressure. Operators rely on them for preventive maintenance and deep descaling. They deliver consistent propulsion, controlled water distribution, and long service life in pipes starting at 200 mm and above.
-
Thread:
$505.00Attributes Value Weight 3.5 lbs Thread 1" – 3/4"
Pipe diameter 6'' – 24'' (recommended)
Rear jet 6 x M 8 // 30º 10º
Water Flow Rate (GPM) Starting from 42
Dimensions (inches) 2.36'' x 5.28''
Weight (lbs) 3.5
-
Thread:
$220.00Attributes Value Weight 1.5 lbs Thread 1" – 3/4"
Pipe diameter 6'' – 20'' (recommended)
Jets (R) 6 X M6 (F) 3 X M6
Water Flow Rate (GPM) Starting from 21
Dimensions (inches) 1.87'' x 3.54''
Weight (lbs) 1.5
-
Thread:
$375.00Attributes Value Weight 2.6 lbs Thread 1” – ¾”
Pipe diameter 6'' – 18'' (recommended)
Jets 6 x M8 // 30º-10º
Water Flow Rate (GPM) Starting from 16
Dimensions (inches) 2.3'' x 5.2''
Weight (lbs) 2.6
-
Thread:
$980.00Attributes Value Weight 19.84 lbs Thread 1” – 3/4"
Pipe diameter 12" – 48" (recommended)
Jets 8x M8 // 5º-10º
Water Flow Rate (GPM) Starting from 53
Dimensions (inches) 5.8" x 8.86" 5.8" x 13.39" (Fitting)
Weight (lbs) 19.84
-
Thread:
$975.00Attributes Value Weight 26.4 lbs Thread 1" – 3/4"
Pipe diameter 12'' – 48'' (recommended)
Jets (R) 5 jets at 15º
Water Flow Rate (GPM) Starting from 53
Dimensions (inches) 5" x 14.1"
Weight (lbs) 26.4
-
Thread:
$785.00Attributes Value Weight 10.1 lbs Thread 1", 3/4"
Pipe diameter 8" – 36" (recommended)
Jets 10 x M8 // 7º – 15º
Water Flow Rate (GPM) Starting at 53
Dimensions (inches) 3.94" x 6.89"
Weight (lbs) 10.1
-
Thread:
$1,230.00Attributes Value Weight 22.05 lbs Thread 1-1/4” // 1”
Pipe diameter 10'' – 48'' (recommended)
Jets 15x M13-1/4” // 7º-15º-20º
Water Flow Rate (GPM) Starting from 53
Dimensions (inches) 4.72" x 7.87"
Weight (lbs) 22.05
-
Thread:
$375.00Attributes Value Weight 2.6 lbs Thread 1”, 3/4”
Pipe diameter 6'' – 18'' (recommended)
Jets 6 x M8 // 30º – 10º
Water Flow Rate (GPM) Starting from 16
Dimensions (inches) 2.36'' x 4.33''
Weight (lbs) 2.6
-
Thread:
$515.00Attributes Value Weight 4.41 lbs Thread 1” – 3/4"
Pipe diameter 6'' – 24'' (recommended)
Jets 12 x M8 // 7º – 14º – 21º
Water Flow Rate (GPM) Starting from 32
Dimensions (inches) 3'' x 5''
Weight (lbs) 4.41
-
Thread:
$570.00Attributes Value Weight 7.9 lbs Thread 1”, 3/4”
Pipe diameter 6" – 24"
Jets 10 x M8 // 30º – 10º
Water Flow Rate (GPM) Starting from 42
Dimensions (inches) 3.15" × 7"
Weight (lbs) 8.82
-
Thread:
$1,365.00Attributes Value Weight 10.14 lbs Thread 1"
Dimensions (body) 9.69" x 9.65"
Weight (lbs) 10.14
Water Flow Rate (GPM) from 53 gpm
-
Thread:
$1,575.00Attributes Value Weight 9.5 lbs Thread 1”
Pipe diameter 8'' – 36'' (recommended)
Jets 2 x M10
Water Flow Rate from 53 gpm
Dimensions (inches) 4.72'' x 8.6''
Weight (lbs) 9.5
-
Thread:
$195.00Attributes Value Weight 1.2 lbs Thread 1"
Pipe diameter 8" – 18" (recommended)
Jets (R) 8 x M6 // 15º-30º // (F) 1 x M6
Water Flow Rate (GPM) Starting from 48
Dimensions (inches) 2" x 3.07"
Weight (lbs) 1.2
